Elko CRM-161 Multifunction Timer Relay

Express Post - $28.00
Australia Post Next Day

Pickup - $0.00 (ETA: 3 days)
Pickup from our Store

Multifunction time relay (6 functions and 6 time ranges), cost eff ective version of CRM-91H. To be used for electrical appliances, control of lights, heating, motors, pumps, fans, etc
6 functions: - 3 time functions controlled by supply voltage
3 time functions controlled by control input
comfortable and well-arranged function and time-range setting by rotary switches
time scale 0.1 s - 10 hrs divided into 6 range:
(0.1 s - 1 s / 1 s - 10 s / 0.1 min - 1 min / 1 min - 10 min / 0.1 hrs - 1 h rs/ 1 hrs - 10 hrs )
universal supply voltage: AC 24-240 V, DC 24 V
output contact: 1x changeover 8 A
output indication: multifunction red LED, which fl ashes or shines in dependance on output status
1-MODULE, DIN rail mounting
